Details

Description

All the essence of Ducati in a modern and contemporary motorcycle. Here is the new Monster in the most compact, essential and lightest possible form.

A project that re-appropriates the original 1993 concepts with a superbike derived frame, in aluminum, which helps to reduce the weight to just 366 lb dry, - 39.6 lb less than the Monster 821.

Narrow sides and a design characterized by simple, clean lines make the bike compact and essential: an engine, a seat, the tank, the handlebars.

Everything you need to have fun, nothing more - the Monster Plus includes a fly fairing and solo seat cover.

Specifications

Engine

Engine Type Testatretta 11°, V2 - 90°, 4 valves per cylinder, desmodromic valvetrain

Displacement 937 cc (57 cu in)

Cooling Liquid cooled

Bore 94 mm

Stroke 67.5 mm

Compression Ratio 13.3:1

Engine Power 111 hp (82 kW) @ 9,250 rpm

Engine Torque 9.5 kgm (93 Nm, 69 lb ft) @ 6,500 rpm

Fuel Injection Electronic fuel injection system, Ø 53 mm throttle bodies with Ride-by-Wire system.

Drivetrain

Gearbox 6 speed

Primary Drive Straight cut gears, ratio 1.85:1

Gear Ratios (overall) 1st 37/15

Gear Ratios (overall) 2nd 30/17

Gear Ratios (overall) 3rd 28/20

Gear Ratios (overall) 4th 26/22

Gear Ratios (overall) 5th 24/23

Gear Ratios (overall) 6th 23/24

Final Drive Chain, front sprocket z15, rear sprocket z43

Clutch Slipper and self-servo multiplate wet clutch with hydraulic control.

Chassis

Frame Type Aluminum alloy Front Frame.

Exhaust Pre-muffler and twin muffler, catalytic converter and 2 lambda probes.

Suspension

Front Suspension Ø 43 mm usd fork

Rear Suspension Progressive linkage, preload adjustable monoshock, aluminum double-sided swingarm.

Brakes

Front braking system 2 x Ø 320 mm semi-floating discs, radially mounted Brembo M4.32 monobloc 4-piston calipers, radial master cylinder, Cornering ABS.

Rear braking system Ø 245 mm disc, Brembo 2-piston floating caliper, Cornering ABS.

Wheels & Tires

Front Wheel Light alloy cast, 3.5" x 17"

Rear Wheel Light alloy cast, 5.5" x 17".

Front Tire Pirelli Diablo Rosso III 120/70 ZR17

Rear Tire Pirelli Diablo Rosso III 180/55 ZR17

Front Wheel Travel 130 mm (5.1 in)

Rear Wheel Travel 140 mm (5.5 in)

Dimensions

Seat Height 820 mm (32.3 in) | 800 mm (31.5 in) (accessory low seat) | 775 mm (30.5 in) (accessory low seat low suspension kit)

Wheelbase 1,474 mm (58.0 in)

Rake/trail 24°/93 mm (3.7 in)

Capacities

Fuel Capacity 14 l (3.7 US gal)

Seating Capacity 2

Weights

Dry Weight 166 kg (366 lb)

Curb Weight 188 kg (414 lb)

Features

Instrumentation 4.3" TFT color display | Maintenance: 30,000 km (18,000 miles) | Valve Clearance Check: 30,000 km (18,000 miles)

Safety Features Riding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light.

Features Standard equipment: Ducati Quick Shift, Ducati Power Launch, 4.3" TFT color display, Full LED headlight and lighting system, Dynamic turn indicators, USB power socket. | Ready for: Ducati Multimedia System, Heated grips.

Warranty

Warranty 24 months, unlimited mileage.
